Anamorphic/i FF

Advancing the evolution of filmmaking

Focal length range: 32mm – 180mm (8 lenses)

Format: Full Frame

Mount: PL or LPL

Speed: T2.3

ID Range

Anamorphic Innovation

Cooke Anamorphic/i is a truly innovative range and the subject of multiple patents. They are for large format production and exemplify anamorphic characteristics combined with The Cooke Look™ including oval bokeh.

Balanced

Anamorphic/i FF
32mm
Anamorphic/i FF
40mm
Anamorphic/i FF
50mm
Anamorphic/i FF
75mm
Anamorphic/i FF Macro
85mm
Anamorphic/i FF
100mm
Anamorphic/i FF
135mm
Anamorphic/i FF
180mm

Eight high-speed focal lengths from 32mm to 180mm, all colour matched for different needs, including a macro focus 85mm lens. Coverage circle covers a full 24 x 36 still size sensor with 1.8x squeeze: the perfect sweet spot.

FEATURES

Hybrid

The Anamorphic/i FF lenses feature a novel hybrid spherical and cylindrical lens element design. It produces a traditional organic, cinematic and anamorphic wide screen quality, which is characterised by smooth, elliptical bokeh and minimal colour fringing to enable you to create sensitive and emotive images with a high degree of dimensionality.

Cooke 32mm Ana-FF+_Rear-34_Black Bkg_10@300_2021-03-08

Special Flair

When specifying your Cooke Anamorphic/i FF, you have the option to have the lens manufactured with a proprietary coating that allows you to kick flares, bokeh and other aberrations into new visual territory.



Image from La Cabeza de Joaquín Murrieta

DoP: Paulo Pérez, ADFC

Murrieta en caballo iglesia resized

Smarter

Cooke’s /i Technology enables cameras to automatically record key lens data for every frame shot, allowing post-production teams to access it digitally. Featuring key information on lens setting, focusing distance, aperture and depth-of-field, hyperfocal distance, serial number and more, it streamlines production and post and saves time and cost to eliminate guesswork.

Comandante_Cooke_Lens_Distortion_001_ON_4K

Handcrafted Precision

Anamorphic lenses are deeply complex to manufacture. Greater anamorphic insights and measurements are taken to ensure absolute quality.

s3-alpha-sig

Showreel

A selection of productions shot on Cooke Anamorphic/i Full Frame lenses.

Anamorphic/i Full Frame Plus 50mm test film

Cinematography by Marie Spencer.

Test Footage

vlcsnap-2023-06-29-11h20m23s653

Showreel

A selection of productions shot on Cooke Anamorphic/i Full Frame lenses.

vlcsnap-2022-11-04-11h25m33s394

Anamorphic/i Full Frame Plus 50mm test film

Cinematography by Marie Spencer.


Anamorphic/i FF Quotes

“The Anamorphic/i lenses create stunning flares – I love an anamorphic flare streak, but I also think it should be selective and appropriate to the project. The Cookes have a subtle version of this and flare beautifully. They are also easy to control if you don’t want flare.”

Tony Slater Ling, BSC | Director of Photography
Anamorphic/i FF Quotes

“Some lenses like these they give you different looks at different stops. So its a lens that performs very well as a workhorse, because the colour rendition and sharpness has a very modern quality. But then you go wide open, all of a sudden there is another characteristic.” “It’s a beautiful set…”

Matthew Libatique | Director of Photography

Credits: Anamorphic/i FF

2023

Lupin

Series 3

Director of Photography: Maxime Cointe & Nicolas Massart
2023

Wonka

Director of Photography: Chung-hoon Chung
2022

Star Trek: Strange New Worlds

Series 1

Directors of Photography: Magdalena Górka, Glen Keenan
2022

Obi-Wan Kenobi

Series 1

Director of Photography: Chung-hoon Chung
2023

Christopher

Director of Photography: Faiz Siddik
2022

Poker Face

Director of Photography: Aaron McLisky ACS
2021

Stillwater

Masanobu Takayanagi
2023

La Cabeza de Joaquín Murrieta

Series 1

Director of Photography: Paulo Andres Perez
2022

The English

Series 1

Arnau Valls Colomer

Specification

The lenses are designed to provide maximum performance at full aperture. The optics feature a 1.8x squeeze factor for full frame formats up to 2.7:1 aspect ratio and a 1.8:1 bokeh shape.

Ergonomically designed to have smooth and accurate travel – whilst utilising precision mechanics to provide a consistent feel in operation through the entire focus movement.

The Cooke /i Technology ecosystem provides critical lens metadata such as focus and iris position. Suitable for the most modern VFX applications such as Virtual Production shooting.

All Anamorphic/i FF lenses are colour balanced and colour matched – ensuring consistency across the series.

We offer a choice of PL and LPL camera mount options, designed specifically for use with our lenses.

All Anamorphic/i FF series lenses are designed for full performance and reliability with a minimum of downtime.

Cooke Anamorphic/i FF provide an aperture range of T2.3-T22 (85mm MACRO T2.8 -T22, 180mm T2.9-T22).

Every focus mark is individually calibrated and engraved on both sides of the focus barrel for ease of use.

All Anamorphic/i FF series lenses have standardised 0.8 MOD focus and iris drive gears.

The Anamorphic/i FF series of prime lenses feature a nine-leaf linear module iris assembly and dual matched iris scales.

Every Cooke lens is coated with a scratch resistant PTFE hard anodised finish, which provides a durable, hard-wearing surface to meet the most demanding environmental conditions.

Technical Data

Metric Imperial

32mm
40mm
50mm
75mm
85mm Macro
100mm
135mm
180mm
Aperture
T2.3 - T22
T2.3 - T22
T2.3 - T22
T2.3 - T22
T2.8 - T22
T2.3 - T22
T2.3 - T22
T2.9 - T22
Iris rotation
90°
90°
90°
90°
90°
90°
90°
90°
Close focus1
900 mm
900 mm
850 mm
1,000 mm
550 mm
1,200 mm
1,500 mm
2,100 mm
Focus rotation
270°
270°
270°
270°
270°
270°
270°
270°
Length2
206 mm
212 mm
204 mm
206 mm
272 mm
228 mm
271 mm
314 mm
Front diameter
136 mm
136 mm
110 mm
110 mm
136 mm
110 mm
110 mm
110 mm
Angle of view (FF)3
H89º / V40º
H78º / V33º
H67º / V27º
H45º / V18º
H39º / V16º
H34º / V14º
H25º / V10º
H19º / V8º
Angle of view (S35)4
H65º / V32º
H55º / V26º
H46º / V21º
H31º / V14º
H27º / V13º
H24º / V11º
H17º / V8º
H13º / V6º
Weight5
4.2 kg
4.4 kg
4 kg
3.5 kg
5.2 kg
3.8 kg
5 kg
6.2 kg
Filter thread
M131 x 1.0
M131 x 1.0
M105 x 0.75
M105 x 0.75
M131 x 1.0
M105 x 0.75
M105 x 0.75
M105 x 0.75
Aperture
T2.3 - T22
T2.3 - T22
T2.3 - T22
T2.3 - T22
T2.8 - T22
T2.3 - T22
T2.3 - T22
T2.9 - T22
Iris rotation
90°
90°
90°
90°
90°
90°
90°
90°
Close focus1
3 ft
3 ft
2 ft 9 in
3 ft 3 in
22 in
4 ft
5 ft
7 ft
Focus rotation
270°
270°
270°
270°
270°
270°
270°
270°
Length2
8.1 in
8.3 in
8 in
8.1 in
10.7 in
9 in
10.6 in
12.4 in
Front diameter
5.3 in
5.3 in
4.3 in
4.3 in
5.3 in
4.3 in
4.3 in
4.3 in
Angle of view (FF)3
H89º / V40º
H78º / V33º
H67º / V27º
H45º / V18º
H39º / V16º
H34º / V14º
H25º / V10º
H19º / V8º
Angle of view (S35)4
H65º / V32º
H55º / V26º
H46º / V21º
H31º / V14º
H27º / V13º
H24º / V11º
H17º / V8º
H13º / V6º
Weight5
9.2 lbs
9.7 lbs
8.8 lbs
7.7 lbs
11.4 lbs
8.4 lbs
11 lbs
13.6 lbs
Filter thread
M131 x 1.0
M131 x 1.0
M105 x 0.75
M105 x 0.75
M131 x 1.0
M105 x 0.75
M105 x 0.75
M105 x 0.75
1Minimum marked object distance (measured from sensor plane). 2From the front of the lens to the lens mount. 3Maximum horizontal and vertical angle of view for Full Frame formats. 4Describes the maximum horizontal and vertical angle of view for Super35 formats. 5Total weight of the lens including base PL mount.
DOWNLOAD SPECIFICATIONS download-icon
