Cooke Anamorphic FF

The next step in the evolution of filmmaking: large format production with anamorphic characteristics, including flare and oval bokeh.

High performance

Superb optical and mechanical performance, control of flare, distortion, veiling glare and spherical aberrations at full aperture.

Balanced

Coverage circle covers a full 24 x 36 still size sensor with 1.8 squeeze - the perfect sweet spot.

Practical

Eight focal lengths for different needs, each featuring the coveted Cooke Look.

Connected

Equipped with /i Technology for frame by frame digital information capture.

See the Range

Anamorphic FF Showreel

Watch our showreel showcasing the latest to be shot on the Cooke Anamorphic/i FF.

Test Footage

Anamorphic/i FF test film

Test Footage

Anamorphic/i FF test film

Test Footage

Anamorphic/i FF test film

Screenshot 2021-01-27 at 19.27.02
Screenshot 2021-05-05 at 11.17.19
Screenshot 2021-05-05 at 11.17.36

Technology

Cooke’s /i Technology automatically collects detailed lens data to equip production, VFX and post-production teams with insight into everything from lens setting to hyperfocal distance. Providing detail on vital information on factors like focus distance, aperture, depth-of-field, owner data and focal length in both metric and footage measurements, it also intelligently gathers inertial tracking data, shading and distortion data.

01
02@2x
03@2x

Shot on Cooke Anamorphic FF

VIEW ALL

Daydream

  • Credits
    • Daydream
    • Director of Photography: Jon Joffin ASC

Handcrafted Innovation

Classic polishing techniques are used to ensure maximum accuracy.

Screenshot 2021-01-14 at 13.25.46

More insights and measurements are collected than ever before to ensure the best possible end result.

Screenshot 2021-01-14 at 13.25.46

Minerals are evaporated at a high temperature in a vacuum to produce a thin film on the glass.

Screenshot 2021-01-14 at 13.25.46

Edging is conducted to ensure that glass diameters are perfectly round.

Screenshot 2021-01-14 at 13.25.46

Lenses are carefully tested, checked, modified, cleaned and rechecked.

Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46

All Features

Optical Design

The Anamorphic/i FF series comprises of 8 Anamorphic Prime Lenses. These Lenses are optimised for film and digital film cameras with the Cooke Look, reduced lateral colour aberration and providing an organic bokeh look. The lenses are designed to provide maximum performance at full aperture with superior control of flare, distortion and spherical aberration. The optics feature a 1.8x squeeze factor for full frame formats up to 2.7:1 aspect ratio and a 1.8:1 bokeh shape.

Colour Balance

All Anamorphic/i FF lenses are colour balanced and colour matched – ensuring consistency across the series.

Aperture

All Anamorphic/i FF lenses cover an image circle greater than full frame.

Iris

The Anamorphic/i FF series of prime lenses feature a nine-leaf linear module iris assembly and dual matched iris scales. Providing an aperture range of T2.3-T22 (85mm MACRO T2.8 -T22, 180mm T2.9-T22).

Focus Movement

Ergonomically designed to have smooth and accurate travel – whilst utilising precision mechanics to provide a consistent feel in operation through the entire focus movement.

Focus Scales

All lenses have individually, factory calibrated, dual matched focus scales with clearly identifiable distance marks.

/I Technology

The Cooke /i Technology ecosystem provides critical lens metadata such as focus and Iris position. Suitable for the most modern VFX applications such as Virtual Production shooting.

Camera Mounts

Precision PL Mount with /i Technology Electrical Contacts.

Standardised

All Anamorphic/i FF series Lenses have standardised 0.8 MOD focus and Iris drive gears.

External Finish

Durable and Hard wearing surface finish to meet the needs of the most demanding environmental conditions.

Weight/Size Ratio

Optimised for the series.

Reliability and Service

All Anamorphic/i FF series lenses are designed for full performance and reliability with a minimum of downtime.

Specifications

T-Stop Range
Angular Rotation of Iris Scale
Min. Marked Object Distance
Close Focus from Lens Front
Angular Rotation to MOD Endstop
Length from Front of Lens to Lens Mount
Max Front Diameter
Total Weight
Max. diagonal angle of view for FF format
DOWNLOAD SPECIFICATIONS download-icon
32mm40mm50mm75mm85mm MACRO100mm135mm180mm
T2.3-T22T2.3-T22T2.3-T22T2.3-T22T2.8-T22T2.3-T22T2.3-T22T2.9-T22
90°90°90°90°90°90°90°90°
900 mm 35 in900 mm 35 in850 mm 33 in1000 mm 39 in500 mm 22 in1200 mm 46 in1500 mm 58 in2000 mm 80 in
630 mm 25 in630 mm 25 in600 mm 24 in750 mm 30 in181 mm 7 in925 mm 36 in1166 mm 46 in1610 mm 63 in
270°270°270°270°270°270°270°270°
206 mm 8.1 in212 mm 8.3 in204 mm 8.0 in206 mm 8.1 in272 mm 10.7 in228 mm 9.0 in271 mm 10.7 in314 mm 12.4 in
136 mm 5.35 in136 mm 5.35 in110 mm 4.33 in110 mm 4.33 in136 mm 5.35 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in
4.2 kg 9.2 lbs4.4 kg 9.7 lbs4.0 kg 8.8 lbs3.5 kg 7.7 lbs5.2 kg 11.4 lbs3.8 kg 8.4 lbs5.0 kg 11.0 lbs6.2 kg 13.6 lbs
99°89°77°52°45°40°30°22°
