Cooke S7 FF

Shoot 35mm, Super 35mm, Full Frame, VistaVision and beyond with the Cooke S7/i Primes, designed to cover the emergent full frame cinema camera sensors up to at least 46.31mm image circle.

Convenient

We have you covered with the ability to shoot in various formats, from 35mm to VistaVision - all with the Cooke Look.

Reliable

Excellent optical and mechanical performance, control of flare, veiling glare, distortion and spherical aberrations at full aperture.

Practical

Colour matched to Anamorphic/i, S4/i, miniS4/i, 5/i and Panchro/i Classic lenses.

Intelligent

Supplied with the next generation of /i Technology for automatic lens metadata capture.

See the Range

S7 Showreel

Watch our showreel showcasing the latest to be shot on the Cooke S7/i.

Test Footage

S7/i test film

Test Footage

S7/i test film

s7i
s7i_2

Technology

Cooke’s /i Technology enables cameras to automatically store key lens data on everything from lens setting and focusing distance to aperture and depth-of-field. Equipping cinematographers with essential information, it streamlines production and post processes while eliminating the need for guesswork.

01
02@2x
03@2x

Shot on Cooke S7

VIEW ALL

Birds of Paradise

  • Credits
    • Birds of Paradise
    • Director of Photography: Shaheen Seth

Handcrafted Precision

Traditional polishing techniques are used to achieve the highest level of precision.

Screenshot 2021-01-14 at 13.25.46

More insights and measurements are taken than ever before to ensure superior quality.

Screenshot 2021-01-14 at 13.25.46

Minerals are evaporated at a high temperature in a vacuum to create a thin film on the glass.

Screenshot 2021-01-14 at 13.25.46

Edging is carried out to ensure that glass diameters are perfectly round.

Screenshot 2021-01-14 at 13.25.46

Lenses are meticulously tested, checked, modified, cleaned and rechecked.

Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46

All Features

Optical Design

The S7/i series are a comprehensive lineup of 14 focal lengths. These Lenses are optimised for film and digital film cameras reducing lateral colour aberration and providing an organic bokeh look. S7/i lenses are designed to provide maximum performance at full aperture with superior control of flare, distortion and spherical aberration – ensuring the Cooke Look remains across the serieso give maximum performance at full aperture with superior control of flare, distortion and spherical aberration.

Aperture

All S7/i primes cover an image circle greater than full frame.

Focus Movement

Ergonomically designed to have smooth and accurate travel – whilst utilising precision mechanics to provide a consistent feel in operation through the entire focus movement.

/I Technology

The Cooke /I Technology ecosystem provides critical lens metadata such as focus and Iris position as well as individually calibrated lens distortion and shading maps. Suitable for the most modern VFX applications such as Virtual Production shooting.

Standardised

All S7/I series Prime lenses have standardised 0.8 MOD focus and Iris drive gears

Weight/Size Ratio

Optimised for the series.

Colour Balance

All S7/i prime lenses are colour balanced and colour matched – ensuring consistency across the series.

Iris

The S7/I series of prime lenses feature a nine-leaf linear module iris assembly. Providing an aperture range of T2-T22

Focus Scales

All lenses have factory calibrated focus scales with clearly identifiable distance marks

Camera Mounts

Precision PL Mount with /i Technology Electrical Contacts

External Finish

Durable and Hard wearing surface finish to meet the needs of the most demanding environmental conditions

Reliability and Service

All S7/I series prime lenses are designed for full performance and reliability with a minimum of downtime

Specifications

T-Stop Range
Angular Rotation of Iris Scale
Min. Marked Object Distance
Close Focus from Lens Front
Angular Rotation to MOD Endstop
Max. Diagonal Angle of View for Super 35 Format
Length from Front of Lens to Lens Mount
Max Front Diameter
Total Weight
Max. diagonal angle of view for FF format
DOWNLOAD SPECIFICATIONS download-icon
16mm18mm21mm25mm27mm32mm40mm50mm65mm75mm100mm135mm180mm300mm
T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T2-T22T3.3-T22
90°90°90°90°90°90°90°90°90°90°90°90°90°90°
400 mm 16 in400 mm 16 in350 mm 14 in350 mm 14 in350 mm 14 in350 mm 14 in450 mm 18 in500 mm 20 in475 mm 19 in475 mm 19 in700 mm 30 in950 mm 39 in1300 mm 51 in2100 mm 81 in
151 mm 6 in158 mm 6 in109 mm 4 in109 mm 4 in109 mm 4 in109 mm 4 in209 mm 8 in259 mm 10 in234 mm 9 in234 mm 9 in459 mm 18 in709 mm 28 in1050 mm 41 in1760 mm 69 in
270°270°270°270°270°270°270°270°270°270°270°270°270°270°
85°78°70°61°56°50°41°33°27°23°17°13°9.6°6.1°
197 mm 7.76 in200 mm 7.87 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in189 mm 7.44 in198 mm 7.80 in256 mm 10.08 in
136 mm 5.35 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in
4.0 kg 8.82 lbs3.5 kg 7.7 lbs3.3 kg 7.28 lbs3.3 kg 7.28 lbs3.3 kg 7.28 lbs3.4 kg 7.50 lbs3.5 kg 7.72 lbs3.4 kg 7.5 lbs3.0 kg 6.61 lbs3.0 kg 6.61 lbs3.3 kg 7.28 lbs3.7 kg 8.16 lbs3.6 kg 7.94 lbs4.4 kg 9.7 lbs
107°100°91°82°76°68°57°47°37°32°24°18°13.7°8.6°
